Insulating glass glue machine

The sealing and structural stability of the insulating glass system are achieved by insulating glass glue. Insulated glass is always faced with the influence of external water vapor penetration and temperature changes during its service life. Therefore, the insulating glass glue must first be able to prevent external water vapor from entering the air layer of the insulated glass. After insulating glass is installed, it often faces the influence of external forces such as temperature differences, air pressure, and wind loads. Therefore, the insulating glass glue is required to ensure the structural stability of the system. Obviously, it is equally important to ensure the sealing of the air layer of the insulating glass and to maintain the structural stability of the insulating glass system. The sealing performance of insulating glass depends on the structural integrity, and the structure ensures the stability of the sealing performance.

Commonly used glues for insulating glass sealing include: silicone glue, glass glue, silica gel, etc. Conventional glue filling machines pour glue into two cylinders, and then proportion, mix, and quantitatively supply the glue to the product through a quantitative pump. However, due to The viscosity of the glue used in insulating glass is very high. It is very difficult to pour the glue into the material tank. Therefore, the difference between the insulating glass gluing machine and the conventional glue filling machine is that the insulating glass gluing machine is customized according to the specifications of the glue barrel used by the customer. Customize the pressure plate and press the glue through the pressure plate when applying glue. The pressure plate is equipped with a piston pump or gear pump to pump glue. The customer only needs to place the glue bucket on the positioning block of the plate pressure machine.

According to the glue, the insulating glass gluing machine can be divided into: single-component gluing machine and two-component gluing machine.

The single-component glue machine is relatively simple. It only needs a pressure plate to draw out the glue and apply it to the product in a quantitative amount.

Two-component glue machine: The principle is the same as the two-liquid dispensing machine. Two pressure plates are customized according to the customer's AB glue barrel. The glue barrel is placed under the pressure plate. The glue is pressed through the pressure plate and then proportioned through the quantitative pump. , mix, and pour onto the product in a quantitative amount. Most of the insulating glass gluing machines currently on the market are piston-type gluing machines. Since the piston type has a glue extraction process, it often causes the gluing lines to become larger and smaller. Therefore, the insulating glass gluing machines of Shengtianqi Technology are all based on the piston type. The precision gear pump can continuously supply glue to pump glue, which can ensure that the glue lines are even and there will be no big or small situations.

Insulating glass gluing machines can be divided into semi-automatic gluing machines and fully automatic gluing machines according to the degree of automation.

Semi-automatic insulating glass gluing machine: The semi-automatic gluing machine is just a device for proportioning, mixing, and quantitative gluing. It is also equipped with a handheld gluing gun. Since the sizes of insulated glass are large, humans need to move the gluing gun to apply the glue. to the insulating glass.

Fully automatic insulating glass gluing machine: The fully automatic insulating glass gluing machine is equipped with a three-axis manipulator. The three-axis manipulator and the gluing machine communicate and cooperate with each other. The gluing machine proportions and mixes the glue and supplies it to the three-axis manipulator in a quantitative manner. The three-axis manipulator can realize gluing operations in various irregular shapes such as semicircles, circles, semicircles, squares, triangles, etc. The itinerary is customized according to the maximum size of the customer's glass.

Features of insulating glass glue machine:

1. The proportion and quantity are accurate, and the glue lines will not be big or small.

2. Extract glue through imported high-precision gear pump, which has high stability and long service life.

3. Install a limit alarm function. After the pressure plate reaches the bottom of the barrel, the equipment will send out an audible and visual alarm to prompt the staff to replace the rubber barrel.

4. The size of the glue output can be adjusted freely according to the actual situation.

Some features of the three-axis machine:

1. Using professional industrial control computers and imported servo motors, the operation is stable and precise.

2. Instructional programming, programming is convenient and fast.

3. Storage capacity: more than 2500 programming points.

4. Optional ball platform or assembly line operation function can make the production efficiency more efficient.

Applicable glue: Silicone glue, high-viscosity silicone glue, glass glue and other high-viscosity glue fluid control operations.
